Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety

Λεπτομέρειες για το προϊόν

Τόπος καταγωγής: Guangzhou, Κίνα

Μάρκα: XINGJIN

Πιστοποίηση: CCC,CAC,ROHS

Αριθμό μοντέλου: XJ-QEO-006

Όροι πληρωμής και αποστολής

Ποσότητα παραγγελίας min: 1 σύνολο συστήματος

Τιμή: Pricing based on quantity

Συσκευασία λεπτομέρειες: Ξύλινο κουτί ή εξωτερικό κουτί με κόντρα πλακέ με τσάντα φούσκας ή χαρτί

Χρόνος παράδοσης: Σύμφωνα με την ποσότητα του προϊόντος

Όροι πληρωμής: T/T, L/C

Δυνατότητα προσφοράς: 3000 σετ/μήνα

Βρείτε την καλύτερη τιμή
Λεπτομέρειες για το προϊόν
Επισημαίνω:
Εφαρμοστέος πυροσβεστικός πράκτορας:
Υπερφθοροεξανόνη, άζωτο
Μέγιστη πίεση πλήρωσης:
60,0 Mpa
Εύρος αποσυμπίεσης αζώτου:
0 ~ 10 MPa Ρυθμιζόμενο (συνήθως χρησιμοποιείται: 4.2 MPa, 5.6 MPa)
Πίεση παραγωγής φαρμάκου:
0 ~ 3.6 MPa
πτυχίο κενού:
≤ -0,09 MPa
Συναγερμός πίεσης πλήρωσης:
0 ~ 10 MPa (ρυθμιζόμενο, το φως συναγερμού θα ενεργοποιηθεί όταν φτάσει στην τιμή καθορισμού)
Γεμίστε την πυκνότητα:
≤ 1420 kg/m³
Ακρίβεια πλήρωσης:
± 0,5%
Θερμοκρασία περιβάλλοντος:
0 ~ 50 ℃
Απαιτήσεις ισχύος:
Εναλλακτικός ρεύμα 220V,50Hz
Μέγεθος εξοπλισμού:
720 × 800 × 1280 mm (εξαιρουμένων του δρομέα)
Νήμα εξωτερικής σύνδεσης:
Σπειρώματα για είσοδο αντιδραστηρίου και διέξοδο και διεπαφή αζώτου: M22 × 1,5
Εφαρμοστέος πυροσβεστικός πράκτορας:
Υπερφθοροεξανόνη, άζωτο
Μέγιστη πίεση πλήρωσης:
60,0 Mpa
Εύρος αποσυμπίεσης αζώτου:
0 ~ 10 MPa Ρυθμιζόμενο (συνήθως χρησιμοποιείται: 4.2 MPa, 5.6 MPa)
Πίεση παραγωγής φαρμάκου:
0 ~ 3.6 MPa
πτυχίο κενού:
≤ -0,09 MPa
Συναγερμός πίεσης πλήρωσης:
0 ~ 10 MPa (ρυθμιζόμενο, το φως συναγερμού θα ενεργοποιηθεί όταν φτάσει στην τιμή καθορισμού)
Γεμίστε την πυκνότητα:
≤ 1420 kg/m³
Ακρίβεια πλήρωσης:
± 0,5%
Θερμοκρασία περιβάλλοντος:
0 ~ 50 ℃
Απαιτήσεις ισχύος:
Εναλλακτικός ρεύμα 220V,50Hz
Μέγεθος εξοπλισμού:
720 × 800 × 1280 mm (εξαιρουμένων του δρομέα)
Νήμα εξωτερικής σύνδεσης:
Σπειρώματα για είσοδο αντιδραστηρίου και διέξοδο και διεπαφή αζώτου: M22 × 1,5
Περιγραφή του προϊόντος

Heptafluoropropane fire extinguishing agent filling equipment


Product Overview:

Heptafluoropropane fire extinguishing agent filling equipment is a professional device that integrates high efficiency, safety and precision, and is suitable for
  Heptafluoropropane fire extinguishing agent filling. The equipment is equipped with nitrogen pressure reduction, filling pressure alarm, vacuum pumping system and weight reporting
  The alarm node reserves interfaces to support multiple gas cylinder specifications, ensuring the airtightness and accuracy during the fire extinguishing agent filling process
Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety 0

Technical Parameter:

Project Parameter
Suitable Extinguishing Media FM200(HFC-227ea),Nitrogen
Maximum Filling Pressure 5.6 MPa
Nitrogen Pressure Reduction Range 0~ 10 MPa adjustable (commonly used: 2.5 MPa, 4.2 MPa, 5.6 MPa)
Drug Output Pressure 0~3.6 MPa
Vacuum Degree ≤ -0.09 MPa
Filling Pressure Alarm 0~ 10 MPa (Adjustable to set value, alarm warning light on)
Filling Density ≤ 950 kg/m³
Filling Accuracy ±0.5%
Ambient Temperature 0~50℃
Power Requirements AC 220V ,50Hz
Equipment Size 720×800×1280 mm (Excluding the wheel)
External Connection Thread Drug inlet and outlet threads and nitrogen interface: M22 × 1.5
Other Reserved weight alarm indicator interface (requires external intelligent electronic weighing device)

Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety 1

 Equipment valve body function:

F1 pressure reducing valve Control the pressure of nitrogen entering the system to ensure stable and safe filling process.
F2 pressure relief valve

Release excess pressure in emergency situations to protect equipment and gas

cylinders from high pressure damage.

F3 Pharmaceutical Storage Valve Control the pipeline for the flow of fire extinguishing agent from the storage tank to the filling cylinder.







F4 nitrogen storage valve Control the entry of nitrogen from the storage tank into the equipment pipeline to provide pressure for the filling of fire extinguishing agents.
F5 gas cylinder valve

Used to connect fire extinguishing agent cylinders and control the opening or closing

of cylinder fluid pipelines.

F6 vacuum valve Used to open or close the air inside the extracted gas cylinder, reduce the pressure inside the cylinder, and ensure the purity of the fire extinguishing agent filling.


FAQ:
Q: Are you a trading company or a manufacturer?
A: We are both a manufacturer and a trading company. We have owned our own factory for nearly 15 years and are committed to providing high-quality service to our overseas customers.

Q: Can you do OEM production?
A: We accept all OEM orders. Simply contact us with your design proposal, and we will provide you with a reasonable price as soon as possible.

Q: How do you ensure product quality?
A: We have TUV/SGS/ISO quality control systems and strictly adhere to them. We have a professional quality inspection team, and each packer conducts a final inspection according to the quality inspection instructions before packaging.

Q: What is the delivery time?
A: Depending on the minimum order quantity, we ship within 10-15 business days after receiving the deposit. 20-foot container orders typically take 30-35 days to fulfill.
Q: Besides filling machines, do you offer other conventional firefighting equipment?
A: Of course. We offer a full range of professional firefighting equipment, from sound and light alarms to smoke exhaust valves, as well as FM200, CO2, and Novec1230 fire suppression systems. Feel free to contact us!
Please inquire about the specific delivery time based on your order quantity.
